Product Description
Product Introduction
The independent photoelectric smoke fire detector detects fires through the principle of dual light path scattering. A
photoelectric sensor designed with a bidirectional special structure uses the scattered light intensity in the smoke detection room to determine the presence of smoke. When the smoke reaches the predetermined threshold, the detector will emit an audible and visual alarm signal, the red indicator light will flash, and the buzzer will sound an alarm. The alarm information can be synchronously pushed to the management platform through the gateway. This product can effectively detect the visible smoke generated by the initial smoldering of a fire, allowing users to promptly eliminate danger or organize personnel evacuation. Suitable for various places such as homes, schools, shops, factories, warehouses, hotels, etc.we also provide software and cloud server for remote monitoring.
photoelectric sensor designed with a bidirectional special structure uses the scattered light intensity in the smoke detection room to determine the presence of smoke. When the smoke reaches the predetermined threshold, the detector will emit an audible and visual alarm signal, the red indicator light will flash, and the buzzer will sound an alarm. The alarm information can be synchronously pushed to the management platform through the gateway. This product can effectively detect the visible smoke generated by the initial smoldering of a fire, allowing users to promptly eliminate danger or organize personnel evacuation. Suitable for various places such as homes, schools, shops, factories, warehouses, hotels, etc.we also provide software and cloud server for remote monitoring.

Product Parameters
General Parameters | |
Transmitting Power:<17dBm | Operating Temperature:-40°C~80°C |
Sensitivity:< - 136dBm | Transmission Distance: >5KM(L OS) |
Transmitting Current :<250mA | Average powerconsumption:< 30uA |
Receiving Current:< 40mA | Battery Life:1 year |
Working Frequency:476.505 & 488.505MHz (frequency can be customized) | Power supply: 2pcs No.5 AA battery |
Sensor Parameters | |
Smoke alarm:yes/no | Transmission Interval: 5-240 minutes) |
